Seat install, airbag question??
11-21-2005 | 05:20 PM
#3
He's as bad as Can
Joined: Feb 2004
Posts: 4,309
Likes: 2
From: Manchester, NJ
you should provide a link to what you installed. Why would you expect an after market seat ( if that is what you have) to work with the MAZDA OEM seat connectors?
EDIT: Now that I know what you have those seats do not have air bags in them. There is no reason to expect them to connect to the OEM seat connectors. Get used to the flashing Air bag light. The other air bags should work FYI.
EDIT: Now that I know what you have those seats do not have air bags in them. There is no reason to expect them to connect to the OEM seat connectors. Get used to the flashing Air bag light. The other air bags should work FYI.
Last edited by expo1; 11-21-2005 at 05:23 PM.
11-21-2005 | 05:31 PM
#5
Thread Starter
SPEED-8
Joined: Oct 2003
Posts: 651
Likes: 1
From: Andorra
Originally Posted by expo1
you should provide a link to what you installed. Why would you expect an after market seat ( if that is what you have) to work with the MAZDA OEM seat connectors?
EDIT: Now that I know what you have those seats do not have air bags in them. There is no reason to expect them to connect to the OEM seat connectors. Get used to the flashing Air bag light. The other air bags should work FYI.
EDIT: Now that I know what you have those seats do not have air bags in them. There is no reason to expect them to connect to the OEM seat connectors. Get used to the flashing Air bag light. The other air bags should work FYI.
11-21-2005 | 05:50 PM
#6
On time, on target
Joined: Mar 2004
Posts: 642
Likes: 0
From: ABQ
Here's what I did. I pulled the wiring harness out of the stock seat, and left it in the car. This let me keep the seat belt switch and the seat track position sensor, so that the OEM airbag sensor was still getting the information it wanted. Then, I put a 1/2W 2 Ohm resistor in the side airbag wiring harness to fake the signal from the side air bag. This keeps the airbag light from going off, and should keep the front airbags functional the way they are supposed to be.
*Disclaimer* I am a tall person and keep my seat all the way back. From what I could tell, the seat track position sensor on the OEM seat only sends its signal when the seat is forward of a certain point. So, since mine is hooked up but not sending a signal, the front airbag should still do a full, two inflator inflation should it ever go off (as opposed to the one inflator inflation it does if it gets the signal that the driver's seat is close to the airbag). I could be wrong.
*Disclaimer* I am a tall person and keep my seat all the way back. From what I could tell, the seat track position sensor on the OEM seat only sends its signal when the seat is forward of a certain point. So, since mine is hooked up but not sending a signal, the front airbag should still do a full, two inflator inflation should it ever go off (as opposed to the one inflator inflation it does if it gets the signal that the driver's seat is close to the airbag). I could be wrong.
11-21-2005 | 08:23 PM
#7
Thread Starter
SPEED-8
Joined: Oct 2003
Posts: 651
Likes: 1
From: Andorra
Originally Posted by ScudRunner
Here's what I did. I pulled the wiring harness out of the stock seat, and left it in the car. This let me keep the seat belt switch and the seat track position sensor, so that the OEM airbag sensor was still getting the information it wanted. Then, I put a 1/2W 2 Ohm resistor in the side airbag wiring harness to fake the signal from the side air bag. This keeps the airbag light from going off, and should keep the front airbags functional the way they are supposed to be.
*Disclaimer* I am a tall person and keep my seat all the way back. From what I could tell, the seat track position sensor on the OEM seat only sends its signal when the seat is forward of a certain point. So, since mine is hooked up but not sending a signal, the front airbag should still do a full, two inflator inflation should it ever go off (as opposed to the one inflator inflation it does if it gets the signal that the driver's seat is close to the airbag). I could be wrong.
*Disclaimer* I am a tall person and keep my seat all the way back. From what I could tell, the seat track position sensor on the OEM seat only sends its signal when the seat is forward of a certain point. So, since mine is hooked up but not sending a signal, the front airbag should still do a full, two inflator inflation should it ever go off (as opposed to the one inflator inflation it does if it gets the signal that the driver's seat is close to the airbag). I could be wrong.
its posibol to send me pics of the install P.M
03-20-2008 | 06:11 PM
#10
Registered
Joined: Oct 2007
Posts: 614
Likes: 0
From: Owings Mills, near Baltimore MD
