The Official Overboosted Overlords Club
#577
Congrats J.Cab.
I got some pics to post in here in a few minutes.
BDC, What Jeff said....also, the more fabrication the better. I figure if we all keep working and fixings problems; then the rest of the club can learn about it... like the IAT sensor thing as a good example.
I got some pics to post in here in a few minutes.
BDC, What Jeff said....also, the more fabrication the better. I figure if we all keep working and fixings problems; then the rest of the club can learn about it... like the IAT sensor thing as a good example.
#578
Registered Noob
Join Date: Sep 2007
Location: Long Island (Suffolk), NY
Posts: 808
Likes: 0
Received 0 Likes
on
0 Posts
ooh, I missed this thread completely. I'll join in.
GaMEChld - Esmeril Turbo Kit
Additional: Esmeril Ignition Upgrade, TurboXS Exhaust, Interceptor-X
Don't have a build thread yet, will keep you posted. This was my first application of FI to any car, and pretty much the first act of automotive tinkering on any car.
GaMEChld - Esmeril Turbo Kit
Additional: Esmeril Ignition Upgrade, TurboXS Exhaust, Interceptor-X
Don't have a build thread yet, will keep you posted. This was my first application of FI to any car, and pretty much the first act of automotive tinkering on any car.
#581
BDC Motorsports
Congrats J.Cab.
I got some pics to post in here in a few minutes.
BDC, What Jeff said....also, the more fabrication the better. I figure if we all keep working and fixings problems; then the rest of the club can learn about it... like the IAT sensor thing as a good example.
I got some pics to post in here in a few minutes.
BDC, What Jeff said....also, the more fabrication the better. I figure if we all keep working and fixings problems; then the rest of the club can learn about it... like the IAT sensor thing as a good example.
B
#582
Thanks for the compliment... wiring was um; interesting.
At this point I am pretty good - just need to work some tuning with the MAF - and I am still not quite 100% on my airflow readings.
But there is always room for improvement - like placing the IAT post turbo and intercooler for more accurate temp corrections. We still have the issues of the Greddy Turbo's and trying to find out how "mod-able" they may be using the stock parts instead of a turbo swap.
Then once we master the streetable 300hp car set-up; phase 2 is to of course turn it up and see what else breaks!
At this point I am pretty good - just need to work some tuning with the MAF - and I am still not quite 100% on my airflow readings.
But there is always room for improvement - like placing the IAT post turbo and intercooler for more accurate temp corrections. We still have the issues of the Greddy Turbo's and trying to find out how "mod-able" they may be using the stock parts instead of a turbo swap.
Then once we master the streetable 300hp car set-up; phase 2 is to of course turn it up and see what else breaks!
#583
BDC Motorsports
Thanks for the compliment... wiring was um; interesting.
At this point I am pretty good - just need to work some tuning with the MAF - and I am still not quite 100% on my airflow readings.
But there is always room for improvement - like placing the IAT post turbo and intercooler for more accurate temp corrections. We still have the issues of the Greddy Turbo's and trying to find out how "mod-able" they may be using the stock parts instead of a turbo swap.
Then once we master the streetable 300hp car set-up; phase 2 is to of course turn it up and see what else breaks!
At this point I am pretty good - just need to work some tuning with the MAF - and I am still not quite 100% on my airflow readings.
But there is always room for improvement - like placing the IAT post turbo and intercooler for more accurate temp corrections. We still have the issues of the Greddy Turbo's and trying to find out how "mod-able" they may be using the stock parts instead of a turbo swap.
Then once we master the streetable 300hp car set-up; phase 2 is to of course turn it up and see what else breaks!
#584
Have to spin back a few pages on the thread.... bu the gist is that the IAT sensor is in the MAF on our cars.... so when you go FI; technically your IAT's are off - so Jeff and Brettus figured out a way to route it past the piping and right before the TB....
The Greddy is a seperate issue - look at the Efficiency Graph thread for details... but some RX& guys have started stepping up to the plate and seeing what they can do with the TD06.
The Greddy is a seperate issue - look at the Efficiency Graph thread for details... but some RX& guys have started stepping up to the plate and seeing what they can do with the TD06.
#586
BDC Motorsports
I would say ideally, without knowing more of the specific issue you guys have run into, that an IAT needs to be as close to the throttle as possible if not past it some. Definitely having it in the MAF up-front is not good.
The Greddy is a seperate issue - look at the Efficiency Graph thread for details... but some RX& guys have started stepping up to the plate and seeing what they can do with the TD06.
B
#587
Life begins @ 30 psi
Join Date: Mar 2008
Location: Columbia, MD
Posts: 1,745
Likes: 0
Received 0 Likes
on
0 Posts
#589
BDC Motorsports
Especially if you wanna spray right at the TB..... now for the alchy guys would the corrosive nature of the spray harm a normal IAT?
I also think that the IAT sensor needs to be placed well past the point of injection. It's something I learned during this last setup go-around. The nozzle placement and where I resultingly put it after-the-fact is what made the whole damn thing work right. Point is it appears there needs to be a given amount of distance to allow an amount of time for the injectant to flash (assuming the use of alcohol here) into a vapour to then yank heat out of the charge as it roars by. A before and after pair of pictures below show more of what I'm talking about. The IAT sensor is located in the 3" machined adaptor just prior to the throttle body. It's location has not changed on this setup. The alcohol nozzles' location(s) did. As far as how this relates to the Rx8 is admittedly a different story.
B
#592
BDC Motorsports
Heh, heh. If you guys get rid of all that plastic junk up front you'd have alot of space, too.
Don't know. I originally had both nozzles parked at the tail-end of the hot-air pipe, bout 3-4" in front of the IAT sensor, with both nozzles facing each other. It didn't seem to work right. IAT's climbed massively and the motor started rattle-canning at low boost (10-15psi). When I decided to move them, I didn't have any kind of calculation or anything like that I applied. I just cut the hot-air pipe in two and placed the nozzles way up stream; one about 4" from the blow-off valve and the other about 10" past that one, staggered.
B
Now here is an interesting question.....how much distance do you have to go for injection in order to assure you get max cooling.....
B
#593
Heh, heh. If you guys get rid of all that plastic junk up front you'd have alot of space, too.
Don't know. I originally had both nozzles parked at the tail-end of the hot-air pipe, bout 3-4" in front of the IAT sensor, with both nozzles facing each other. It didn't seem to work right. IAT's climbed massively and the motor started rattle-canning at low boost (10-15psi). When I decided to move them, I didn't have any kind of calculation or anything like that I applied. I just cut the hot-air pipe in two and placed the nozzles way up stream; one about 4" from the blow-off valve and the other about 10" past that one, staggered.
B
Don't know. I originally had both nozzles parked at the tail-end of the hot-air pipe, bout 3-4" in front of the IAT sensor, with both nozzles facing each other. It didn't seem to work right. IAT's climbed massively and the motor started rattle-canning at low boost (10-15psi). When I decided to move them, I didn't have any kind of calculation or anything like that I applied. I just cut the hot-air pipe in two and placed the nozzles way up stream; one about 4" from the blow-off valve and the other about 10" past that one, staggered.
B
#594
Dongbag extrordinare
Join Date: Nov 2004
Location: Away from the fruits of my labor
Posts: 1,090
Likes: 0
Received 0 Likes
on
0 Posts
In fact, I think I'll put it up for sale on this forum as soon as I get home.
-Yambo
#596
Nope
iTrader: (9)
So Chickenwafer got officially dyno'ed.
I got my misfire issue solved thanks to CRH- I had the wrong terminals on my MSD plug wires. I crimped them down with my needle noses and no more misfire! Schweet.
I ran pretty conservative on the dyno since I don't have a final tune and I was running lean prior. Jeff tweaking the MAF scaling so I was running richer. Boost was only 9-9.8psi.
302-rwhp, 231 ft-lbs torque:
Also had some cut-out at higher rpm thanks to injecting too much water/alky mix. I dialed it down and it feel better. Tony (the guy at the shop/UMS Tuning) said I could have picked up a few more horses if that was dialed back.
All in all I'm pretty happy- conservative tune, low boost, and I'm in the 300-whp club! Next up, more boost, race gas. We'll see...
I got my misfire issue solved thanks to CRH- I had the wrong terminals on my MSD plug wires. I crimped them down with my needle noses and no more misfire! Schweet.
I ran pretty conservative on the dyno since I don't have a final tune and I was running lean prior. Jeff tweaking the MAF scaling so I was running richer. Boost was only 9-9.8psi.
302-rwhp, 231 ft-lbs torque:
Also had some cut-out at higher rpm thanks to injecting too much water/alky mix. I dialed it down and it feel better. Tony (the guy at the shop/UMS Tuning) said I could have picked up a few more horses if that was dialed back.
All in all I'm pretty happy- conservative tune, low boost, and I'm in the 300-whp club! Next up, more boost, race gas. We'll see...
#599
Dongbag extrordinare
Join Date: Nov 2004
Location: Away from the fruits of my labor
Posts: 1,090
Likes: 0
Received 0 Likes
on
0 Posts
Nice curve wafer. You definately have more power available. I have been waiting to see other dynos on this kit besides the one Jeff posted in the dyno comparo thread.(I am forgetfull and probably forgot if I saw others before). If I were turboed, that is the type of curve I would want to have
#600
For all you GReddy users that need/will need to do fix#2....found this little beauty at atp turbo...no need to weld, or tap into your pipe and worry about screwing something up (like me )
clicky for link
clicky for link
